OK-6, 3" KICKOVER TOOL
The “OK-6” Kickover Tool is used to install and retrieve 1” devices in side pocket mandrels with an orienting sleeve. The “OK-6” uses a ball detent and spring design to promote easy redress operation.
- Fishneck
- Centralizer Sleeve
- Cap Screew
- Locator Finger
- Leaf Springs
- 8/32 Screws
- Finger Housing
- Shear Pin
- Core Spring
- Release Plunger
- Finger Cage
- Lock Ring
- Half Dog Set Screw
- Arm Pin
- Arm Adapter
- 1/2" TC Ball
- Spring Insert
- Kick Springs
- Detent Spring
- Arm
- Ball Seat
- 9/16"TC Ball
- Arm Pin
- Lower Adapter
- Housing
- Nose
3"
FISHNECK O.D.
1.375"
MAX. O.D.
2.727"
MAKE UP LENGTH
70.062"
STEEL PIN - FINGER
RELEASE PLUNGER
1/4" X 1 3/8"
3/16" X 1 1/2"
SET SCREW
3/8" - 16 X .250
BUTTON HEAD SCREW
1/4" - 20 X 3/8"
TOP PIN THREAD
15/16" - 10
VALVE
1"
MANDREL TYPE
KBMG, KBG
Items
Description Part Number
Qty R'qed
1. BUTTON HEAD SET SCREW
15904-004-00000
2 2. CENTRALIZING SPRING
15904-005-00000
2 3. FISHING NECK
13291-001-00000
1 4. FINGER CAGE
13291-003-00000
1 5. LOCATING FINGER
15905-004-00000
1 6. FINGER SPRING
15289-013-00000
3 7. SCREW 8 - 32 - 1/4
40002-053-00000
2 8. LOCK WASHER
B0000-006-00000
2 9. SHEAR PIN
15905-009-00000
1 10. FINGER HOUSING
15903-003-00000
1 11. SHEAR PIN
15319-009-00000
1 12. SET SCREW
50337-029-00000
1 13. RETURN SPRING
15156-004-00000
1 14. RELEASE PLUNGER
15905-005-00000
1 15. LOCK RING
15905-006-00000
1 16. FULL DOG ALLEN SET SCREW
15247-020-00000
1 17. ARM PIN
15289-007-00000
2 18. ARM ADAPTER
15903-005-00000
1 19. T.C BALL
02004-003-00000
1 20. UPPER DETENT SLEEVE
15903-015-00000
1 21. SOCKET HEAD CAP SCREW
15308-008-00000
2 22. DETENT SPRING
15903-016-00000
1 23. KICK SPRING
15255-015-00000
3 24. ARM
15903-006-00000
1 25. LOWER DETENT PLUNGER
15255-B00-00000
1 26. LOWER ADAPTER
15903-007-00000
1 27. HOUSING ASSEMBLY
13291-B00-00000
1 28. NOSE
15905-008-00000
1 29. CENTRALIZER 13291-002-00000
1
